تفاصيل المنتج:
|
| الجهد المقنن: | تيار مستمر 24 فولت | عقد الحالي: | 0.32 |
|---|---|---|---|
| قوة: | 7.7 | درجة حرارة العمل: | -5 - 50 (درجة مئوية) |
| ضغط العمل: | 0.3 - 0.8 (ميجا باسكال) | ||
| إبراز: | Pneumatic solenoid double valves,Press machine solenoid valves,K23JSD-L series pneumatic valves,Press machine solenoid valves,K23JSD-L series pneumatic valves |
||
| Type | Nominal Dia | A | P | 0 | M | N | L | G | H |
| K23JSD-L15 | 15 | G1/2 | G1/2 | G3/4 | 90 | 155 | 226 | 135 | 41 |
| K23JSD-L20 | 20 | G3/4 | G3/4 | G1-1/4 | 105 | 170 | 246 | 149 | 52 |
| K23JSD-L25 | 25 | G1 | G1 | G1-1/4 | 105 | 170 | 246 | 149 | 52 |
| K23JSD-L32 | 32 | G1-1/4 | G1-1/4 | G2 | 127 | 254 | 259 | 212 | 77 |
| K23JSD-L40 | 40 | G1-1/2 | G1-1/2 | G2 | 127 | 254 | 259 | 212 | 77 |
| Parameters | Type | K23JSD-L15 | K23JSD-L20 | K23JSD-L25 | K23JSD-L32 | K23JSD-L40 |
| dia | 15 | 20 | 25 | 30 | 40 | |
| port size | P | G1/2 | G3/4 | G1 | G1-1/4 | G1-1/2 |
| A | G1/2 | G3/4 | G1 | G1-1/4 | G1-1/2 | |
| 0 | G3/4 | G1-1/4 | G1-1/4 | G2 | G2 | |
| Range of working pressure(Hpa) | 0.3-0.8 | |||||
| Working temperatureC) | -5~50 | |||||
| Direction changing Time(sec) | ≤0.05 | ≤0.07 | ≤0.07 | ≤0.10 | ≤0.10 | |
|
Effective sectional area Cv(mm²) |
P-A | >30 | >90 | >90 | >140 | >140 |
| A-0 | ≥120 | ≥360 | ≥360 | ≥560 | >560 | |
| Valve Type | K23JSD-L | K23JSD-L | K23JSD-L | K23JSD-L | K23JSD-L | K23JSD-L |
| Rated Voltage | AC100V 50HZ | AC100V 60HZ | AC110V 60HZ | AC200V 50HZ | AC200V 60HZ | AC220V 60HZ |
| Starting Current | 0.29 | 0.25 | 0.27 | 0.14 | 0.12 | 0.13 |
| Holding Current | 0.15 | 0.12 | 0.15 | 0.08 | 0.06 | 0.07 |
| Power Consumption (W) | 8 | 7 | 9 | 8 | 7 | 9 |
| Valve Type | K23JSD-L |
| Rated Voltage | DC 24V |
| Holding Current | 0.32 |
| Power Consumption (W) | 7.7 |
